Trie

Trees & HeapsPriority 4 of 5 — High value — a gap here costs you roundsHigh value Updated Sep 18, 2026
Section priorityPriority 5 of 5 — Must know — expect it in almost every loopMust knowPriority 4 of 5 — High value — a gap here costs you roundsHigh valuePriority 3 of 5 — Worth knowing — usually a variant of a must-know patternWorth knowingPriority 2 of 5 — Niche — read once, revisit only if a company is known to askNicheMarked on the sections that carry it — unmarked sections are background/reference.

Scope — The prefix tree — insert/search/startsWith, node layout choices, and the problems where sharing prefixes is the whole trick (autocomplete, word search, XOR trie). See also: trie_examples.md — the five worked problems behind these templates; string.md — string handling without a trie; hash_map.md — when a set of whole words is enough; dfs.md — the traversal trie problems run on top; advanced_string_algorithms.md — suffix-based alternatives.

Whenever we come across questions with multiple strings, it is best to think if Trie can help us.

LeetCode Problem Lists

Time Complexity

Data structure Search Insert Delete Min/Max
Trie O(L) O(L) O(L) O(L)

L = length of the key (word) — complexities are independent of the number of stored keys. Min/Max = lexicographically smallest / largest key.

0) Concept

0-1) Types

  • HashMap-based trie — children is a dict/Map; flexible alphabet (see Pattern below).
  • Array-based trie — children is a fixed [None] * 26 / TrieNode[26]; fastest for lowercase-only (Template 2).
  • Wildcard trie — supports . matching via DFS over all children (Template 3, LC 211).
  • Binary (XOR) trie — children are bits 0/1; used for max-XOR / bitwise problems (Template 5, LC 421).

0-2) Pattern

python
class TrieNode:
    def __init__(self):
        self.children = {}  # HashMap for flexible alphabet
        self.is_end = False
        self.word = None    # Store complete word (optional)

class Trie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        """Insert word into trie. Time: O(m), Space: O(m)"""
        node = self.root
        for char in word:
            if char not in node.children:
                node.children[char] = TrieNode()
            node = node.children[char]
        node.is_end = True
        node.word = word  # Store for easy retrieval

    def search(self, word: str) -> bool:
        """Search for exact word. Time: O(m)"""
        node = self.root
        for char in word:
            if char not in node.children:
                return False
            node = node.children[char]
        return node.is_end

    def startsWith(self, prefix: str) -> bool:
        """Check if any word starts with prefix. Time: O(p)"""
        node = self.root
        for char in prefix:
            if char not in node.children:
                return False
            node = node.children[char]
        return True
java
// Java version
class TrieNode {
    Map<Character, TrieNode> children;
    boolean isEnd;
    String word;

    public TrieNode() {
        children = new HashMap<>();
        isEnd = false;
        word = null;
    }
}

class Trie {
    private TrieNode root;

    public Trie() {
        root = new TrieNode();
    }

    public void insert(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            node.children.putIfAbsent(c, new TrieNode());
            node = node.children.get(c);
        }
        node.isEnd = true;
        node.word = word;
    }

    public boolean search(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            if (!node.children.containsKey(c)) {
                return false;
            }
            node = node.children.get(c);
            if (node == null) return false;  // null-check guard
        }
        return node.isEnd;
    }

    public boolean startsWith(String prefix) {
        TrieNode node = root;
        for (char c : prefix.toCharArray()) {
            if (!node.children.containsKey(c)) {
                return false;
            }
            node = node.children.get(c);
            if (node == null) return false;  // null-check guard
        }
        return true;
    }
}

Templates & Algorithms

Template 1 is the hash-map trie in 0-2) Pattern above. Everything below is that same structure with one thing changed: the child container, what a walk is allowed to do at a node, or what the “alphabet” is.

Template 2: Trie with Array (Fixed Alphabet)

python
class TrieNode:
    def __init__(self):
        self.children = [None] * 26  # For lowercase letters only
        self.is_end = False

class Trie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        node = self.root
        for char in word:
            idx = ord(char) - ord('a')
            if not node.children[idx]:
                node.children[idx] = TrieNode()
            node = node.children[idx]
        node.is_end = True

    def search(self, word: str) -> bool:
        node = self._search_prefix(word)
        return node is not None and node.is_end

    def startsWith(self, prefix: str) -> bool:
        return self._search_prefix(prefix) is not None

    def _search_prefix(self, prefix: str) -> TrieNode:
        node = self.root
        for char in prefix:
            idx = ord(char) - ord('a')
            if not node.children[idx]:
                return None
            node = node.children[idx]
        return node
java
// Java version
class TrieNode {
    TrieNode[] children;
    boolean isEnd;

    public TrieNode() {
        children = new TrieNode[26];
        isEnd = false;
    }
}

Template 3: Trie with Wildcard Support — LC 211

python
class WildcardTrie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        node = self.root
        for char in word:
            if char not in node.children:
                node.children[char] = TrieNode()
            node = node.children[char]
        node.is_end = True

    def search(self, word: str) -> bool:
        """Search with '.' as wildcard for any character"""
        return self._dfs_search(word, 0, self.root)

    def _dfs_search(self, word: str, index: int, node: TrieNode) -> bool:
        if index == len(word):
            return node.is_end

        char = word[index]
        if char == '.':
            # Try all possible children
            if not node.children:
                return False
            for child in node.children.values():
                if self._dfs_search(word, index + 1, child):
                    return True
            return False
        else:
            if char not in node.children:
                return False
            return self._dfs_search(word, index + 1, node.children[char])
java
// Java version
public boolean search(String word) {
    return dfsSearch(word, 0, root);
}

private boolean dfsSearch(String word, int index, TrieNode node) {
    if (index == word.length()) {
        return node.isEnd;
    }

    char c = word.charAt(index);
    if (c == '.') {
        for (TrieNode child : node.children.values()) {
            if (dfsSearch(word, index + 1, child)) {
                return true;
            }
        }
        return false;
    } else {
        if (!node.children.containsKey(c)) {
            return false;
        }
        return dfsSearch(word, index + 1, node.children.get(c));
    }
}

Template 4: Autocomplete Trie — LC 1268

python
class AutocompleteTrie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        node = self.root
        for char in word:
            if char not in node.children:
                node.children[char] = TrieNode()
            node = node.children[char]
        node.is_end = True
        node.word = word

    def search_prefix(self, prefix: str, limit: int = 3) -> List[str]:
        """Return up to 'limit' words with given prefix"""
        node = self.root

        # Navigate to prefix end
        for char in prefix:
            if char not in node.children:
                return []
            node = node.children[char]

        # Collect all words with this prefix
        results = []
        self._dfs_collect(node, results, limit)
        return results

    def _dfs_collect(self, node: TrieNode, results: List[str], limit: int):
        if len(results) >= limit:
            return

        if node.is_end:
            results.append(node.word)

        # Traverse in lexicographical order
        for char in sorted(node.children.keys()):
            self._dfs_collect(node.children[char], results, limit)
java
// Java version with priority queue for top suggestions
class AutocompleteTrie {
    class TrieNode {
        Map<Character, TrieNode> children = new HashMap<>();
        Map<String, Integer> counts = new HashMap<>();  // Word -> frequency
    }

    public List<String> getTopSuggestions(String prefix, int k) {
        TrieNode node = root;
        for (char c : prefix.toCharArray()) {
            if (!node.children.containsKey(c)) {
                return new ArrayList<>();
            }
            node = node.children.get(c);
        }

        // Use heap to get top k
        PriorityQueue<Map.Entry<String, Integer>> pq = new PriorityQueue<>(
            (a, b) -> b.getValue() - a.getValue()
        );
        pq.addAll(node.counts.entrySet());

        List<String> result = new ArrayList<>();
        while (!pq.isEmpty() && result.size() < k) {
            result.add(pq.poll().getKey());
        }
        return result;
    }
}

Template 5: Binary Trie (XOR Problems) — LC 421 Priority 3 of 5 — Worth knowing — usually a variant of a must-know pattern

python
class BinaryTrie:
    class Node:
        def __init__(self):
            self.children = [None, None]  # 0 and 1
            self.count = 0

    def __init__(self):
        self.root = self.Node()

    def insert(self, num: int) -> None:
        """Insert number as 32-bit binary"""
        node = self.root
        for i in range(31, -1, -1):
            bit = (num >> i) & 1
            if not node.children[bit]:
                node.children[bit] = self.Node()
            node = node.children[bit]
            node.count += 1

    def find_max_xor(self, num: int) -> int:
        """Find maximum XOR with num"""
        node = self.root
        max_xor = 0

        for i in range(31, -1, -1):
            bit = (num >> i) & 1
            # Try to go opposite direction for max XOR
            toggled = 1 - bit

            if node.children[toggled] and node.children[toggled].count > 0:
                max_xor |= (1 << i)
                node = node.children[toggled]
            else:
                node = node.children[bit]

        return max_xor

    def remove(self, num: int) -> None:
        """Remove number from trie"""
        node = self.root
        for i in range(31, -1, -1):
            bit = (num >> i) & 1
            node = node.children[bit]
            node.count -= 1
java
// Java version
class BinaryTrie {
    class Node {
        Node[] children = new Node[2];
        int count = 0;
    }

    private Node root = new Node();

    public void insert(int num) {
        Node node = root;
        for (int i = 31; i >= 0; i--) {
            int bit = (num >> i) & 1;
            if (node.children[bit] == null) {
                node.children[bit] = new Node();
            }
            node = node.children[bit];
            node.count++;
        }
    }

    public int findMaxXor(int num) {
        Node node = root;
        int maxXor = 0;

        for (int i = 31; i >= 0; i--) {
            int bit = (num >> i) & 1;
            int toggled = 1 - bit;

            if (node.children[toggled] != null && node.children[toggled].count > 0) {
                maxXor |= (1 << i);
                node = node.children[toggled];
            } else {
                node = node.children[bit];
            }
        }

        return maxXor;
    }
}

Template 6: Trie with Delete Operation

Delete algorithm — 3-step recursive logic:

  1. Navigate to the end of the word; if the word doesn’t exist, return False.
  2. Unmark is_end at the terminal node.
  3. During backtracking, remove any child node that is now both a non-terminal leaf (no children, not end of another word) — this cleans up dangling nodes.

Key invariant: only delete a node if it has no remaining children AND is not the end of a different word. Shared prefixes must be preserved.

text
Example: trie contains "apple" and "app"

delete("apple"):
  Unmark 'e'.is_end  →  'e' has no children, not is_end → delete 'e'
                         'l' now has no children, not is_end → delete 'l'
                         second 'p' now has no children BUT is_end ("app" ends here) → STOP

  Result: "app" is still intact.
python
# python — complete Trie with delete
class TrieNode:
    def __init__(self):
        self.children = {}
        self.is_end = False

class Trie:
    def __init__(self):
        self.root = TrieNode()

    def insert(self, word: str) -> None:
        node = self.root
        for ch in word:
            if ch not in node.children:
                node.children[ch] = TrieNode()
            node = node.children[ch]
        node.is_end = True

    def search(self, word: str) -> bool:
        node = self.root
        for ch in word:
            if ch not in node.children:
                return False
            node = node.children[ch]
        return node.is_end

    def startsWith(self, prefix: str) -> bool:
        node = self.root
        for ch in prefix:
            if ch not in node.children:
                return False
            node = node.children[ch]
        return True

    def delete(self, word: str) -> bool:
        """
        Delete word from trie. Returns True if word existed and was deleted.
        Cleans up leaf nodes that are no longer needed.
        """
        def _delete(node: TrieNode, word: str, depth: int) -> bool:
            if depth == len(word):
                if not node.is_end:
                    return False          # word not in trie
                node.is_end = False
                # This node can be removed if it has no children
                return len(node.children) == 0

            ch = word[depth]
            if ch not in node.children:
                return False              # word not in trie

            should_delete_child = _delete(node.children[ch], word, depth + 1)

            if should_delete_child:
                del node.children[ch]
                # Propagate deletion upward only if this node is also a bare leaf
                return len(node.children) == 0 and not node.is_end

            return False

        return _delete(self.root, word, 0)
java
// java — complete Trie with delete
class TrieNode {
    Map<Character, TrieNode> children = new HashMap<>();
    boolean isEnd = false;
}

class Trie {
    private TrieNode root = new TrieNode();

    public void insert(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            node.children.putIfAbsent(c, new TrieNode());
            node = node.children.get(c);
        }
        node.isEnd = true;
    }

    public boolean search(String word) {
        TrieNode node = root;
        for (char c : word.toCharArray()) {
            if (!node.children.containsKey(c)) return false;
            node = node.children.get(c);
        }
        return node.isEnd;
    }

    public boolean startsWith(String prefix) {
        TrieNode node = root;
        for (char c : prefix.toCharArray()) {
            if (!node.children.containsKey(c)) return false;
            node = node.children.get(c);
        }
        return true;
    }

    public boolean delete(String word) {
        return _delete(root, word, 0);
    }

    // Returns true if the current node can be safely removed by its parent.
    private boolean _delete(TrieNode node, String word, int depth) {
        if (depth == word.length()) {
            if (!node.isEnd) return false;   // word not in trie
            node.isEnd = false;
            // Safe to delete this node if it has no children
            return node.children.isEmpty();
        }

        char ch = word.charAt(depth);
        TrieNode child = node.children.get(ch);
        if (child == null) return false;     // word not in trie

        boolean shouldDeleteChild = _delete(child, word, depth + 1);

        if (shouldDeleteChild) {
            node.children.remove(ch);
            // Propagate upward only if this node is also a bare leaf
            return node.children.isEmpty() && !node.isEnd;
        }

        return false;
    }
}

Trace — delete("apple") when trie also contains "app":

text
depth=0  ch='a'  → recurse
depth=1  ch='p'  → recurse
depth=2  ch='p'  → recurse
depth=3  ch='l'  → recurse
depth=4  ch='e'  → recurse
depth=5  (end)   isEnd=true → set isEnd=false, children={} → return true (delete 'e')
depth=4  remove 'e', children={}, isEnd=false             → return true (delete 'l')
depth=3  remove 'l', children={}, isEnd=false             → return true (delete 2nd 'p')
depth=2  remove 2nd 'p', children={}, BUT isEnd=true ("app" ends here) → return false ✓
depth=1,0  no deletion propagated upward

Result: "app" intact, "apple" gone ✓

Patterns not covered by Templates 1-6. Each one is a different way of walking the trie — the trie itself barely changes.

Signal in the problem Template Worked example
“split a string into dictionary words” Template 7 — Trie + DP LC 139, LC 472
“concatenate two words into a palindrome” Template 8 — Reversed-word trie LC 336
“lexicographic / dictionary order of numbers” Template 9 — Implicit 10-ary digit trie LC 386
“replace a word by its shortest root/prefix” Template 1 variation — stop at first is_end LC 648

Template 7: Trie + DP (Word Segmentation) — LC 139 Priority 5 of 5 — Must know — expect it in almost every loop

Key Idea: dp[i] = "s[0..i) can be segmented". From every reachable index i, walk the trie forward one char at a time; every time you land on an is_end node at position j, set dp[j+1] = True. The trie replaces the inner “try every dictionary word” loop — you break out the moment the prefix leaves the trie, so no hashing of substrings is needed.

python
# python
# LC 139 - Word Break
# IDEA: trie of wordDict + dp over s; from each reachable index walk the trie forward
# time = O(n^2 + M), space = O(n + M)   # n = len(s), M = total chars in wordDict
class TrieNode(object):
    def __init__(self):
        self.children = {}
        self.is_end = False

class Solution(object):
    def wordBreak(self, s, wordDict):
        root = TrieNode()
        for w in wordDict:
            node = root
            for ch in w:
                if ch not in node.children:
                    node.children[ch] = TrieNode()
                node = node.children[ch]
            node.is_end = True

        n = len(s)
        dp = [False] * (n + 1)
        dp[0] = True   # empty prefix is always segmentable

        for i in range(n):
            if not dp[i]:
                continue          # unreachable start -> skip
            node = root
            for j in range(i, n):
                ch = s[j]
                ### NOTE : the moment s[i..j] leaves the trie, no longer prefix can match
                if ch not in node.children:
                    break
                node = node.children[ch]
                if node.is_end:
                    dp[j + 1] = True
        return dp[n]
java
// java
// LC 139 - Word Break
// IDEA: trie of wordDict + dp[i] = "s[0..i) is segmentable"; walk trie from every reachable i
class TrieNode {
    Map<Character, TrieNode> children = new HashMap<>();
    boolean isEnd = false;
}

class Solution {
    public boolean wordBreak(String s, List<String> wordDict) {
        // time = O(n^2 + M), space = O(n + M)  // n = s.length(), M = total chars in wordDict
        TrieNode root = new TrieNode();
        for (String w : wordDict) {
            TrieNode node = root;
            for (char c : w.toCharArray()) {
                node.children.putIfAbsent(c, new TrieNode());
                node = node.children.get(c);
            }
            node.isEnd = true;
        }

        int n = s.length();
        boolean[] dp = new boolean[n + 1];
        dp[0] = true;   // empty prefix is always segmentable

        for (int i = 0; i < n; i++) {
            if (!dp[i]) continue;          // unreachable start -> skip
            TrieNode node = root;
            for (int j = i; j < n; j++) {
                node = node.children.get(s.charAt(j));
                if (node == null) break;   // prefix left the trie
                if (node.isEnd) dp[j + 1] = true;
            }
        }
        return dp[n];
    }
}

Variation — LC 472 Concatenated Words: same trie + DP, but the answer needs at least 2 pieces and a word must not be built from itself. Twist: sort words by length and insert lazily — when testing w, the trie holds only strictly shorter words, so any successful segmentation automatically uses ≥ 2 of them.

python
# python
# LC 472 - Concatenated Words
# IDEA: LC 139's trie+dp, but test each word against a trie of only the STRICTLY SHORTER words
# time = O(N * L^2), space = O(total chars)   # N = #words, L = max word length
class Solution(object):
    def findAllConcatenatedWordsInADict(self, words):
        root = TrieNode()

        def can_form(w):
            n = len(w)
            dp = [False] * (n + 1)
            dp[0] = True
            for i in range(n):
                if not dp[i]:
                    continue
                node = root
                for j in range(i, n):
                    if w[j] not in node.children:
                        break
                    node = node.children[w[j]]
                    if node.is_end:
                        dp[j + 1] = True
            return dp[n]

        def insert(w):
            node = root
            for ch in w:
                if ch not in node.children:
                    node.children[ch] = TrieNode()
                node = node.children[ch]
            node.is_end = True

        res = []
        ### NOTE : sort by length -> trie only ever holds shorter words -> >= 2 pieces guaranteed
        for w in sorted(words, key=len):
            if not w:
                continue
            if can_form(w):
                res.append(w)
            insert(w)
        return res

Template 8: Reversed-Word Trie (Palindrome Pairing) — LC 336

Key Idea: words[i] + words[j] is a palindrome iff one word “covers” the reverse of the other and the leftover middle part is itself a palindrome. So insert every reversed word into a trie and store two things per node:

  • word_index — a reversed word ends exactly here
  • palindrome_below — indices of words whose remaining suffix below this node is a palindrome

Then walking words[i] down the trie splits into exactly 2 cases:

text
case 1 (words[j] is SHORTER): hit a node with word_index = j after k chars
        words[i] = [ reverse(words[j]) ][ leftover ]   -> valid iff leftover is a palindrome

case 2 (words[j] is LONGER/equal): consumed all of words[i], now at node `node`
        reverse(words[j]) = [ words[i] ][ leftover ]   -> valid iff leftover is a palindrome
                                                          (exactly node.palindrome_below)

The two cases are disjoint by length, so no pair is emitted twice.

python
# python
# LC 336 - Palindrome Pairs
# IDEA: trie of REVERSED words; node stores the word ending there + words with palindromic remainder
# time = O(N * L^2), space = O(N * L)   # N = #words, L = max word length
class PairNode(object):
    def __init__(self):
        self.children = {}
        self.word_index = -1        # a reversed word ends here
        self.palindrome_below = []  # words whose remaining suffix below here is a palindrome

class Solution(object):
    def palindromePairs(self, words):

        def is_pal(s, i, j):
            while i < j:
                if s[i] != s[j]:
                    return False
                i += 1
                j -= 1
            return True

        root = PairNode()
        # build : insert reverse(word)
        for idx, word in enumerate(words):
            n = len(word)
            node = root
            for k in range(n):
                ### NOTE : remaining reversed suffix == reverse(word[0 .. n-1-k])
                if is_pal(word, 0, n - 1 - k):
                    node.palindrome_below.append(idx)
                ch = word[n - 1 - k]
                if ch not in node.children:
                    node.children[ch] = PairNode()
                node = node.children[ch]
            node.palindrome_below.append(idx)   # empty remainder is a palindrome
            node.word_index = idx

        res = []
        for idx, word in enumerate(words):
            node = root
            fell_off = False
            for k, ch in enumerate(word):
                # CASE 1 : a shorter reversed word ends here
                if node.word_index != -1 and node.word_index != idx \
                        and is_pal(word, k, len(word) - 1):
                    res.append([idx, node.word_index])
                if ch not in node.children:
                    fell_off = True
                    break
                node = node.children[ch]
            if fell_off:
                continue
            # CASE 2 : word is a prefix of these reversed words
            for j in node.palindrome_below:
                if j != idx:
                    res.append([idx, j])
        return res
java
// java
// LC 336 - Palindrome Pairs
// IDEA: trie of REVERSED words; node stores the word ending there + words with palindromic remainder
class Solution {
    // time = O(N * L^2), space = O(N * L)   // N = #words, L = max word length
    class PairNode {
        Map<Character, PairNode> children = new HashMap<>();
        int wordIndex = -1;                                // a reversed word ends here
        List<Integer> palindromeBelow = new ArrayList<>(); // palindromic remainder below here
    }

    private PairNode root;

    public List<List<Integer>> palindromePairs(String[] words) {
        root = new PairNode();   // rebuild per call — LeetCode reuses one Solution object
        for (int i = 0; i < words.length; i++) insertReversed(words[i], i);

        List<List<Integer>> res = new ArrayList<>();
        for (int i = 0; i < words.length; i++) search(words[i], i, res);
        return res;
    }

    private void insertReversed(String word, int idx) {
        PairNode node = root;
        int n = word.length();
        for (int k = 0; k < n; k++) {
            // remaining reversed suffix == reverse(word[0 .. n-1-k])
            if (isPalindrome(word, 0, n - 1 - k)) node.palindromeBelow.add(idx);
            char c = word.charAt(n - 1 - k);
            node.children.putIfAbsent(c, new PairNode());
            node = node.children.get(c);
        }
        node.palindromeBelow.add(idx);   // empty remainder is a palindrome
        node.wordIndex = idx;
    }

    private void search(String word, int idx, List<List<Integer>> res) {
        PairNode node = root;
        for (int k = 0; k < word.length(); k++) {
            // CASE 1 : a shorter reversed word ends here -> rest of `word` must be a palindrome
            if (node.wordIndex != -1 && node.wordIndex != idx
                    && isPalindrome(word, k, word.length() - 1)) {
                res.add(Arrays.asList(idx, node.wordIndex));
            }
            PairNode next = node.children.get(word.charAt(k));
            if (next == null) return;
            node = next;
        }
        // CASE 2 : `word` is a prefix of these reversed words
        for (int j : node.palindromeBelow) {
            if (j != idx) res.add(Arrays.asList(idx, j));
        }
    }

    private boolean isPalindrome(String s, int i, int j) {
        while (i < j) {
            if (s.charAt(i++) != s.charAt(j--)) return false;
        }
        return true;
    }
}

The "" (empty word) case is handled for free: it terminates at the root, so root.palindromeBelow is exactly “every word that is itself a palindrome”.

Template 9: Implicit Digit Trie (Lexicographic Numbers) — LC 386

Key Idea: 1..n is a 10-ary trie you never have to build — node x has children x*10 .. x*10+9, and roots are 1..9. A pre-order DFS of that trie emits numbers in lexicographic order. Doing the DFS iteratively gives O(1) extra space.

text
n = 13         1              2 ... 9
             / | \
           10 11 12 13        pre-order -> 1, 10, 11, 12, 13, 2, 3, ... 9

Move rules (the whole algorithm):

  • go deeper: cur * 10 (if cur * 10 <= n)
  • else go to next sibling: cur + 1
  • if the sibling doesn’t exist (cur % 10 == 9 or cur + 1 > n), backtrack with cur //= 10 first
python
# python
# LC 386 - Lexicographical Numbers
# IDEA: 1..n is an implicit 10-ary trie; pre-order DFS of it == lexicographic order
# time = O(n), space = O(1) extra (excluding output)
class Solution(object):
    def lexicalOrder(self, n):
        res = []
        cur = 1
        for _ in range(n):
            res.append(cur)
            if cur * 10 <= n:
                cur *= 10           # go DEEPER (append digit 0)
            else:
                ### NOTE : climb up while there is no next sibling
                while cur % 10 == 9 or cur + 1 > n:
                    cur //= 10
                cur += 1            # next SIBLING
        return res
java
// java
// LC 386 - Lexicographical Numbers
// IDEA: 1..n is an implicit 10-ary trie; pre-order DFS of it == lexicographic order
class Solution {
    public List<Integer> lexicalOrder(int n) {
        // time = O(n), space = O(1) extra (excluding output)
        List<Integer> res = new ArrayList<>();
        int cur = 1;
        for (int i = 0; i < n; i++) {
            res.add(cur);
            if ((long) cur * 10 <= n) {
                cur *= 10;                 // go DEEPER
            } else {
                // climb up while there is no next sibling
                while (cur % 10 == 9 || cur + 1 > n) {
                    cur /= 10;
                }
                cur += 1;                  // next SIBLING
            }
        }
        return res;
    }
}

Template 1 variation — Shortest Root Replacement — LC 648

Twist: while walking a word down a normal trie, stop at the FIRST is_end node — that is the shortest dictionary root, which is exactly what LC 648 asks to substitute in.

python
# python
# LC 648 - Replace Words
# IDEA: standard trie; when walking each word, return at the FIRST is_end node (shortest root)
# time = O(M + S), space = O(M)   # M = total chars in dictionary, S = total chars in sentence
class Solution(object):
    def replaceWords(self, dictionary, sentence):
        root = TrieNode()
        for w in dictionary:
            node = root
            for ch in w:
                if ch not in node.children:
                    node.children[ch] = TrieNode()
                node = node.children[ch]
            node.is_end = True

        def shortest_root(word):
            node = root
            for i, ch in enumerate(word):
                if ch not in node.children:
                    break
                node = node.children[ch]
                if node.is_end:
                    return word[:i + 1]   ### NOTE : first is_end wins
            return word

        return " ".join(shortest_root(w) for w in sentence.split())
java
// java
// LC 648 - Replace Words
// IDEA: standard trie; when walking each word, return at the FIRST isEnd node (shortest root)
class Solution {
    public String replaceWords(List<String> dictionary, String sentence) {
        // time = O(M + S), space = O(M)  // M = total dict chars, S = total sentence chars
        TrieNode root = new TrieNode();
        for (String w : dictionary) {
            TrieNode node = root;
            for (char c : w.toCharArray()) {
                node.children.putIfAbsent(c, new TrieNode());
                node = node.children.get(c);
            }
            node.isEnd = true;
        }

        StringBuilder sb = new StringBuilder();
        for (String word : sentence.split(" ")) {
            if (sb.length() > 0) sb.append(" ");
            sb.append(shortestRoot(root, word));
        }
        return sb.toString();
    }

    private String shortestRoot(TrieNode root, String word) {
        TrieNode node = root;
        for (int i = 0; i < word.length(); i++) {
            node = node.children.get(word.charAt(i));
            if (node == null) break;
            if (node.isEnd) return word.substring(0, i + 1);  // first isEnd wins
        }
        return word;
    }
}

1) General form

1-1) Basic OP

See the insert / search / startsWith skeletons in 0-2) Pattern and the variant templates above (array-based, wildcard, autocomplete, binary/XOR, delete).

Advanced Trie Variants — XOR Trie, Stream Matching, Delete

XOR Trie — LC 421, compact reference

The full walkthrough is Template 5 above; this is the same idea at a glance. Use a binary trie (bits 0/1 as children) to find the maximum XOR between any two numbers.

python
class XORTrie:
    def __init__(self):
        self.root = {}

    def insert(self, num):
        node = self.root
        for i in range(31, -1, -1):
            bit = (num >> i) & 1
            node = node.setdefault(bit, {})

    def max_xor(self, num):
        node = self.root
        xor = 0
        for i in range(31, -1, -1):
            bit = (num >> i) & 1
            want = 1 - bit          # prefer the opposite bit
            if want in node:
                xor |= (1 << i)
                node = node[want]
            else:
                node = node[bit]
        return xor

# LC 421
def findMaximumXOR(nums):
    trie = XORTrie()
    for n in nums:
        trie.insert(n)
    return max(trie.max_xor(n) for n in nums)

Trie + DP (Stream Matching) — LC 1032 Stream of Characters

Combine a trie of reversed words with the stream so far, and walk the stream backwards.

Complexity: the walk stops at the first character with no trie child, so a query costs O(L) where L is the longest dictionary word — not O(1), and not O(stream) either, as long as you cap what you keep. The version below appends to self.stream forever, so its walk is bounded by the stream length; keeping only the last L characters (a deque(maxlen=L)) is what makes it O(L) per query and O(L) memory.

python
class StreamChecker:
    def __init__(self, words):
        self.trie = {}
        self.stream = []
        # Insert reversed words — query from end of stream
        for w in words:
            node = self.trie
            for c in reversed(w):
                node = node.setdefault(c, {})
            node['#'] = True

    def query(self, letter: str) -> bool:
        self.stream.append(letter)
        node = self.trie
        # Walk stream backwards through trie
        for c in reversed(self.stream):
            if c not in node:
                return False
            node = node[c]
            if '#' in node:
                return True
        return False

Trie delete — compact reference

The full implementation is Template 6 above; this is the invariant it maintains, stated on its own.

python
# NOTE !!! two different booleans are in play, and conflating them is the classic bug:
#   - `deleted`  -- was the WORD removed?          (what the caller asked)
#   - `prune`    -- may the parent drop this node? (an internal signal)
# Returning the prune signal as the result reports False for "delete('a')" when "ab"
# also exists, because the node survives as a prefix even though the word is gone.
def delete(self, word: str) -> bool:
    deleted = False

    def _delete(node, depth):
        nonlocal deleted
        if depth == len(word):
            if not node.is_end:
                return False              # word was never here -> nothing to prune
            node.is_end = False
            deleted = True
            return len(node.children) == 0
        ch = word[depth]
        if ch not in node.children:
            return False
        if _delete(node.children[ch], depth + 1):
            del node.children[ch]
            return len(node.children) == 0 and not node.is_end
        return False

    _delete(self.root, 0)
    return deleted

Prefix-Suffix Trie — LC 745

For problems requiring both prefix and suffix matching, wrap each word as suffix#word and insert into one trie.

python
# For word "apple", insert: "apple#apple", "pple#apple", ..., "e#apple", and "#apple"
# NOTE !!! range(len(word) + 1) -- the last iteration inserts the EMPTY suffix, which is
#          what makes a query with suffix "" matchable. range(len(word)) silently drops it.
def buildIndex(words):
    trie = {}
    for weight, word in enumerate(words):
        for i in range(len(word) + 1):
            key = word[i:] + '#' + word
            node = trie
            for c in key:
                node = node.setdefault(c, {})
            node['weight'] = weight  # store latest (highest) weight
    return trie

Interview tips — trie

Signal Pattern
“prefix matching”, “autocomplete” Standard trie
“maximum XOR”, “bitwise optimization” Binary XOR trie
“stream of characters”, “real-time matching” Reversed-word trie + state
“both prefix AND suffix” Suffix#word trie
“wildcard . matching” DFS at . nodes
“count words with prefix” Add count field to TrieNode

Also solvable with a trie (no new template)

  • LC 14 Longest Common Prefix — insert all words, then walk down from the root while a node has exactly 1 child and is not is_end; the path walked is the answer. (The plain vertical scan is simpler in an interview — mention the trie only if asked for repeated queries.)

Worked Examples

Five problems live in trie_examples.md:

Group Problems
Building the structure LC 208, 211
Searching with it LC 1268, 79, 212

LC 79 is in there without a trie on purpose: it is the baseline that makes LC 212 legible — the same grid DFS, run once per word, until the trie collapses all the words into one walk.

← Back to Cheat Sheets Edit on GitHub →
